Samway P20AP 1 1/4" Hydraulic Hose Crimping Machine
Price:
sales@samway.com
SKU:
Samway P20AP 1 1/4" Hydraulic Hose Crimping Machine
Brand:
Weight:
N/A
Availability:
Samway P20AP 1 1/4" Hydraulic Hose Crimping Machine
Product Description
Samway P20AP 1 1/4" Hydraulic Hose Crimping Machine
Feature description：
● Portable 1 ½" Crimper
● No electricity required
● Enerpac Hand Pump
● Complete Die Set
P20AP Hydraulic Hose Crimping Machine
Specification：
| Main Specification |
SAMWAY P20AP |
| Max Hydraulic Hose |
1 ½" 4SP |
| Crimping Range mm |
4-75 |
| Die Type |
P20 |
| Master Die Length mm |
80 |
| Max Opening mm |
+25 |
| Hand Pump |
Enerpac two stage Pneumatic pump 700 bar |
| Crimping Force KN |
1400 |
| Control |
Micro Dail |
| L*W*H mm |
487*440*270 |
| Weight KG |
55 |
Standard Die Sets Included：
| Die No. | 10* | 12* | 14 | 16 | 19 | 22 | 26 | 30 | 34 | 39 | 45 | 51* | 57* |
| Length |
55 | 55 | 55 | 55 | 55 | 55 | 75 | 75 | 90 | 90 | 90 | 90 | 90 |
* Optional Die Sets Upon Request
Order No.
Hand Pump Model P20HP :00002010
Pneumatic Pump Model P20AP :00002011
Warranty Information
1 year
